- In a recent endurance test, the 933EHD recorded 14.5% higher operational efficiency than previous models. With a high-capacity (1.88 m3) bucket, we help you move more material for a lower cost.
- ROPS and FOPS protection, a fully adjustable seat, automatic climate control,sunshades, ample storage and ergonomic design. lt all adds up to create the luxurious experience professional operators expect.
- With an advanced hydraulic system, the main pump and main valve are precisely calibrated to deliver better control, improved efficiency and faster cycle times.
933EHD
Operating Weight:
33,600 kg
Rated Power:
169 kW
Bucket Capacity:
1.6 m?
933EHD
Unit：
- Metric
- U.S
Product Features
933EHD
933EHD
Specifications
| Operating weight | 33600 kg |
| Engine power | 169 kW @ 2200 rpm |
| Std. Bucket capacity | 1.6 m? |
| Travel speed(High) | 5.5 km/h |
| Travel speed(Low) | 3.0 km/h |
| Maximum swing speed | 10.3 rpm |
| Arm breakout force | 137 kN |
| Arm breakout force Power boost | 149 kN |
| Bucket breakout force | 187 kN |
| Bucket breakout force Power boost | 203 kN |
| Shipping length | 10650 mm |
| Shipping width | 3190 mm |
| Shipping height | 3525 mm |
| Track shoe width (std) | 600 mm |
| Boom | 6200 mm |
| Arm | 3050 mm |
| Digging reach | 10653 mm |
| Digging reach on ground | 10453 mm |
| Digging depth | 7300 mm |
| Vertical wall digging depth | 6216 mm |
| Cutting height | 10300 mm |
| Dumping height | 7265 mm |
| Minimum front swing radius | 4040 mm |
| Model | Cummins QSB7 |
| Emission | Stage III / Tier 3 |
| System maximum flow | 2×266 L/min (2x70 gal/min) |
| System pressure | 34.3 MPa |
| Download Brochure |
※For reference only.
